Broadband Waveguide Horn Antenna Operating from 1 GHz to 18 GHz with a Nominal 11 dBi Gain, N Female Input Connector

$1,199.90 USD
Shipping calculated at checkout.
Just 4 left. Order soon!
Spend $500.00 to FREE SHIPPING
DATASHEET Available--->Click to download

Product Description

GHA0118A-11 is a Broadband Waveguide Horn Antenna Operating from 1 GHz to 18 GHz with a Nominal 11 dBi Gain, N Female Input Connector RF antenna that covers the frequency range from . This antenna has a Aluminum body and ensures an excellent microwave performance with high gain 11 dBi and VSWR of 2.5. This antenna is precisely manufactured to RF industries like military & space, RF communication, test & measurement and industrial applications..

This radio frequency antenna is part of over 10,000 RF, microwave and millimeter wave products that ship the same day worldwide, including custom cable assemblies. For further information on similar products, our expert technical support and knowledgeable sales team can help you get the high-quality 110 GHz radio frequency adapter that meets your requirements.

Specifications

Product Configuration:
Connector Series: N
Connector Polarity: Standard
Connector Gender: Female
Connector Impedance (Ohm): 50
Antenna Type: Horn

Electrical Specifications:
Directionality: Directional
Polarization: Linear
Number of Bands: Single
Gain, Typical (dBi): 11
Power, Max Input (Watts): 50
Beam Width, 3dB H (Deg): 33
Beam Width, 3dB V (Deg): 47

Mechanical Data:
Body Material: Aluminum
Colour: Silver
Weight(g): 1,429

Environmental Specifications:
Operating Temperature Range: -40 ºC to +80 ºC
RoHS Compliant: Yes

For more information, please download product datasheet above for reference.
